INSTALLATION

This is the basic information on the installation of TwinLite® – multiwall polycarbonate roofing sheet. Please read and follow the installation’s instruction carefully before starting. For more detail information, please refer to Twinlite® manual installation book.

01 GENERAL

  • Always install TwinLite® sheets with Ultra Violet (UV)
    protected surface facing the sun. Ensure that the labeled
    side of the sheet is identified before installation.
  • Please ensure to remove the masking film from TwinLite®
    sheets after installation to prevent the masking film sticking
    to the sheet due to the heat exposure from sunlight.

CAUTION: misplacing the UV side will void the warranty of the sheet.

UV Side Protected Surface Facing the Sun

03 EXPANSION ALOWNESS

TwinLite® sheets are installed with rust proof fasteners and weather seals for each bar structures. Holes should be drilled at the range of 2 mm from the diameter of fasteners as this allows for thermal expansion during noontime and contraction at night. The number of fasteners used should be in accordance with the specification of the profile being used.

Lubang dibor dengan posisi tegak 90o
Penggunaan pengencang anti karat dan tahan cuaca

05 JOINING THE SHEETS

Using H Polycarbonate Profile
You can use H profile made of polycarbonate sheet or aluminium.

joining-th-sheetjoining-th-sheet-1

Menggunakan profil H Aluminium

06 GASKETS

Neoprene, TPE, or EPDM rubbers with an approximate shore hardness of A65 are recommended for their compatibility.

NEVER USE PVC gaskets. PVC is incompatible with polycarbonate, and will harm the panel. Damage caused by this will nullify the warranty.

07 SEALANTS

Prior to using sealant, please ensure their chemical compatibility with polycarbonate.

08 POSITIONING THE SHEETS

Prior to using sealant, please ensure their chemical compatibility with polycarbonate.TwinLite® sheets should be installed with the rib in the direction of the slope (flat), vertical (partition), or following the direction of the arched rafters (dome). This position reduces accumulation of dirt inside the sheet and ease gravity drainage of condensation moisture.

Pemasangan mengikuti arah lengkungan (kubah)

For the sheets installed in the clamped, horizontal position, (Roofs, overhead skylight), a minimum slope of 5 percent is recommended. Steeper slope offer better rainwater drainage and self cleaning, and lessen the risk of water and dirt filtration through the connectors and fastening screw. They also help to diminish the visual effect of sheet deflection due to the loads.

Pemasangan searah dengan lereng (rata)

09 ARCHED INSTALLATION

The following is the recommended the sheet’s radius of arched storage and installation.

Pemasangan polycarbonate yang direkomendasikan

10 CLEANING

Should cleaning be required, simply wet the sheet with water, use a mild household detergent, a soft clean cloth or soft sponges, then hose off. Only use regular non-alkaline soaps.

CAUTION: Please avoid the usage of thinner,gasoline or strong acids.
